基于 QuickAdd+Modal Form 的任务 (Task) 编辑器

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--

关于 QuickAdd+ModalForm 版的 Task 编辑器,推荐设置快捷键 Ctrl + Shift + K

Task 简介

Task 编辑器

Task 自带的任务编辑器,可以用来调整任务状态,可以通过 Tasks:Create or edit task 命令或者它的 API 调用 Task 的编辑器,eg: 调用 Task API 即可,采用 QuickAdd Capture 模式:

// Source: https://publish.obsidian.md/tasks/Advanced/Tasks+Api
return await this.app.plugins.plugins['obsidian-tasks-plugin'].apiV1.createTaskLineModal() + '\n';

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--Task 编辑器

优先级 (Priority)

  • ⏬Lowest|🔽Low|Normal|🔼Medium|⏫High|🔺Highest
  • 可以将其按照四象限法则结构划分为 4 个等级
    • 🔴重要且紧急⏫|🟠不重要但紧急🔼|🟡重要但不紧急🔽|🟢不重要不紧急⏬

任务状态 (Status)

状态符号下一个状态符号状态名称状态类型
空格x待办TODO
x空格已完成DONE
/x进行中IN_PROGRESS
-空格取消CANCELLED

Loading graph...

可以自行导入其他主题的样式

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--任务状态 (Status)

拓展:【CSS】Minimal 主题复选框 (Checkout) 样式

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--拓展:【CSS】Minimal 主题复选框 (Checkout) 样式

/* task选择器样式 来自Minimal v7.5.4 by 熊猫别熬夜*/

input[data-task="!"]:checked,
input[data-task="*"]:checked,
input[data-task="-"]:checked,
input[data-task="<"]:checked,
input[data-task=">"]:checked,
input[data-task=I]:checked,
input[data-task=b]:checked,
input[data-task=c]:checked,
input[data-task=d]:checked,
input[data-task=f]:checked,
input[data-task=k]:checked,
input[data-task=l]:checked,
input[data-task=p]:checked,
input[data-task=u]:checked,
input[data-task=w]:checked,
li[data-task="!"]>input:checked,
li[data-task="!"]>p>input:checked,
li[data-task="*"]>input:checked,
li[data-task="*"]>p>input:checked,
li[data-task="-"]>input:checked,
li[data-task="-"]>p>input:checked,
li[data-task="<"]>input:checked,
li[data-task="<"]>p>input:checked,
li[data-task=">"]>input:checked,
li[data-task=">"]>p>input:checked,
li[data-task=I]>input:checked,
li[data-task=I]>p>input:checked,
li[data-task=b]>input:checked,
li[data-task=b]>p>input:checked,
li[data-task=c]>input:checked,
li[data-task=c]>p>input:checked,
li[data-task=d]>input:checked,
li[data-task=d]>p>input:checked,
li[data-task=f]>input:checked,
li[data-task=f]>p>input:checked,
li[data-task=k]>input:checked,
li[data-task=k]>p>input:checked,
li[data-task=l]>input:checked,
li[data-task=l]>p>input:checked,
li[data-task=p]>input:checked,
li[data-task=p]>p>input:checked,
li[data-task=u]>input:checked,
li[data-task=u]>p>input:checked,
li[data-task=w]>input:checked,
li[data-task=w]>p>input:checked {
	--checkbox-marker-color: transparent;
	border: none;
	border-radius: 0;
	background-image: none;
	background-color: currentColor;
	-webkit-mask-size: var(--checkbox-icon);
	-webkit-mask-position: 50% 50%
}

input[data-task=">"]:checked,
li[data-task=">"]>input:checked,
li[data-task=">"]>p>input:checked {
	color: var(--text-faint);
	transform: rotate(90deg);
	-webkit-mask-position: 50% 100%;
}

input[data-task="<"]:checked,
li[data-task="<"]>input:checked,
li[data-task="<"]>p>input:checked {
	color: var(--text-faint);
}

input[data-task="?"]:checked,
li[data-task="?"]>input:checked,
li[data-task="?"]>p>input:checked {
	--checkbox-marker-color: transparent;
	background-color: var(--color-yellow);
	border-color: var(--color-yellow);
	background-position: 50% 50%;
	background-size: 200% 90%;
}

.theme-dark input[data-task="?"]:checked,
.theme-dark li[data-task="?"]>input:checked,
.theme-dark li[data-task="?"]>p>input:checked {
}

input[data-task="/"]:checked,
li[data-task="/"]>input:checked,
li[data-task="/"]>p>input:checked {
	background-image: none;
	background-color: rgba(0, 0, 0, 0);
	position: relative;
	overflow: hidden
}

input[data-task="/"]:checked:after,
li[data-task="/"]>input:checked:after,
li[data-task="/"]>p>input:checked:after {
	top: 0;
	left: 0;
	content: " ";
	display: block;
	position: absolute;
	background-color: var(--background-modifier-accent);
	width: calc(50% - .5px);
	height: 100%;
	-webkit-mask-image: none
}

input[data-task="!"]:checked,
li[data-task="!"]>input:checked,
li[data-task="!"]>p>input:checked {
	color: var(--color-orange);
}

input[data-task='"']:checked,
input[data-task=]:checked,
li[data-task='"']>input:checked,
li[data-task='"']>p>input:checked,
li[data-task=]>input:checked,
li[data-task=]>p>input:checked {
	--checkbox-marker-color: transparent;
	background-position: 50% 50%;
	background-color: var(--color-cyan);
	border-color: var(--color-cyan);
	background-size: 75%;
	background-repeat: no-repeat;
}

.theme-dark input[data-task='"']:checked,
.theme-dark input[data-task=]:checked,
.theme-dark li[data-task='"']>input:checked,
.theme-dark li[data-task='"']>p>input:checked,
.theme-dark li[data-task=]>input:checked,
.theme-dark li[data-task=]>p>input:checked {
}

input[data-task="-"]:checked,
li[data-task="-"]>input:checked,
li[data-task="-"]>p>input:checked {
	color: var(--text-faint);
}

body:not(.tasks) .markdown-preview-view ul li[data-task="-"].task-list-item.is-checked,
body:not(.tasks) .markdown-source-view.mod-cm6 .HyperMD-task-line[data-task]:is([data-task="-"]),
body:not(.tasks) li[data-task="-"].task-list-item.is-checked {
	color: var(--text-faint);
	text-decoration: line-through solid var(--text-faint) 1px
}

input[data-task="*"]:checked,
li[data-task="*"]>input:checked,
li[data-task="*"]>p>input:checked {
	color: var(--color-yellow);
}

input[data-task=l]:checked,
li[data-task=l]>input:checked,
li[data-task=l]>p>input:checked {
	color: var(--color-red);
}

input[data-task=i]:checked,
li[data-task=i]>input:checked,
li[data-task=i]>p>input:checked {
	--checkbox-marker-color: transparent;
	background-color: var(--color-blue);
	border-color: var(--color-blue);
	background-position: 50%;
	background-size: 100%;
}

.theme-dark input[data-task=i]:checked,
.theme-dark li[data-task=i]>input:checked,
.theme-dark li[data-task=i]>p>input:checked {
}

input[data-task=S]:checked,
li[data-task=S]>input:checked,
li[data-task=S]>p>input:checked {
	--checkbox-marker-color: transparent;
	border-color: var(--color-green);
	background-color: var(--color-green);
	background-size: 100%;
}

.theme-dark input[data-task=S]:checked,
.theme-dark li[data-task=S]>input:checked,
.theme-dark li[data-task=S]>p>input:checked {
}

input[data-task=I]:checked,
li[data-task=I]>input:checked,
li[data-task=I]>p>input:checked {
	color: var(--color-yellow);
}

input[data-task=f]:checked,
li[data-task=f]>input:checked,
li[data-task=f]>p>input:checked {
	color: var(--color-red);
}

input[data-task=k]:checked,
li[data-task=k]>input:checked,
li[data-task=k]>p>input:checked {
	color: var(--color-yellow);
}

input[data-task=u]:checked,
li[data-task=u]>input:checked,
li[data-task=u]>p>input:checked {
	color: var(--color-green);
}

input[data-task=d]:checked,
li[data-task=d]>input:checked,
li[data-task=d]>p>input:checked {
	color: var(--color-red);
}

input[data-task=w]:checked,
li[data-task=w]>input:checked,
li[data-task=w]>p>input:checked {
	color: var(--color-purple);
}

input[data-task=p]:checked,
li[data-task=p]>input:checked,
li[data-task=p]>p>input:checked {
	color: var(--color-green);
}

input[data-task=c]:checked,
li[data-task=c]>input:checked,
li[data-task=c]>p>input:checked {
	color: var(--color-orange);
}

input[data-task=b]:checked,
li[data-task=b]>input:checked,
li[data-task=b]>p>input:checked {
	color: var(--color-orange);
}

基于 Modal Form 的 Task 编辑器

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--基于 Modal Form 的 Task 编辑器

关于 QuickAdd+ModalForm 版的 Task 编辑器,推荐设置快捷键 Ctrl + Shift + K

可设置的参数

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--可设置的参数

Quickadd 脚本

module.exports = {
  entry: async (QuickAdd, settings, params) => {
    let modalForm;
    try {
      modalForm = app.plugins.plugins.modalforms.api;
    } catch {
      new Notice("🔴本脚本需要Modal Form插件,请先安装或启动Modal Form插件!");
      return;
    }
    let type = true;
    let taskContent = ""; let tags = "";
    let startStr = "";
    let reminderDate = ""; let reminderTime = "";
    let createdDate = ""; let createdTime = ""; let createdTime2 = "";
    // 记录时间差
    let hours = 0; let minutes = 0;

    let due = "";
    let priority = "";
    let recurs = "";
    let status = "";
    // !获取当前编辑器
    let editor;
    try {
      editor = app.workspace.activeEditor.editor;
      // 选择所在的一行
      const line = editor.getLine(editor.getCursor().line);
      let selection = line ? line.replace(/<br>/gm, "\n") : "- [ ] ";
      console.log(selection);
      // 切换列表为复选框
      if (selection.match(/(^[\t\s>-]*-\s)(?!\[)/)) {
        selection = selection.replace(/(^[\t\s]*-\s)(?!\[)/, "$1[ ] ");
        type = false;
      }
      // !提取任务信息
      let regex = /(^[\t\s->]+-?)\s\[(.)\]\s(\d{2}:\d{2})?(\s-\s(\d{2}:\d{2})?)?([^🔽🔼⏬⏫🔁➕📅⏰⏳🛫✅]*)/;
      let matches = selection.match(regex);
      if (matches) {
        startStr = matches[1] ? matches[1] : "";
        status = matches[2] ? matches[2] : "";
        taskContent = matches[6] ? matches[6] : "";
        tags = taskContent.match(/\s(#\S+)/gm);
        console.log(`标签: ${tags}`);
        // 移除任务内容中的标签
        taskContent = taskContent.replace(/\s#[^\s]+/gm, "").trim();
      }

      // !提取优先级
      let priorityRegex = /(🔽|🔼|||🔺)/;
      let priorityMatches = selection.match(priorityRegex);
      priority = priorityMatches ? priorityMatches[1] : "";

      // !提取重复周期🔁
      let recursRegex = /(🔁\severy)\s(\d+)?\s?(day|week)(\son\s\w+)?/;
      let recursMatches = selection.match(recursRegex);
      recurs = recursMatches ? (recursMatches[1] + " " + (recursMatches[3] + (recursMatches[4] !== undefined ? recursMatches[4] : ""))) : "";
      console.log(recurs);


      // !提取任务创建日期和时间➕
      let createRegex = /🛫\s(\d{4}-\d{2}-\d{2})\s(\d{2}:\d{2})?/;
      let createMatches = selection.match(createRegex);

      if (createMatches) {
        createdDate = createMatches[1] ? createMatches[1] : "";
        // createdTime = createMatches[2] ? createMatches[2] : "";
      }
      if (settings["AutoCreatedDate"]) {
        createdDate = createdDate ? createdDate : window.moment().format("YYYY-MM-DD");
      }

      // !2024-04-30_10:58 具体创建时间放到列表前面,适配其他时间线插件(Day Planer (OG)(✨) 和 Day Planer)
      // Day Planer (OG)可能更容易上手点,Day Planner 稍微复杂,流程比较多,可能需要多测试
      let createdTimeRegex = /\]\s(\d{2}:\d{2})?(\s-\s(\d{2}:\d{2}))?/;

      let createdTimeMatches = selection.match(createdTimeRegex);
      if (createdTimeMatches) {
        createdTime = createdTimeMatches[1] ? createdTimeMatches[1] : "";
        createdTime2 = createdTimeMatches[3] ? createdTimeMatches[3] : "";
        console.log([createdTime, createdTime2]);

        // 使用window.moment()计算createdTime2 - createdTime的时间差
        const timeFormat = 'HH:mm';

        const startTime = window.moment(createdTime, timeFormat);
        const endTime = window.moment(createdTime2, timeFormat);

        const duration = window.moment.duration(endTime.diff(startTime));
        hours = Math.floor(duration.asHours());
        minutes = Math.round(duration.asMinutes() % 60);

        const timeDiff = `${hours}小时${minutes}分钟`;
        console.log(timeDiff);
      }
      if (settings["AutoTime"]) {
        createdTime = createdTime ? createdTime : window.moment().format("HH:mm");
      }

      // !提取提醒日期和时间⏰
      let startRegex = /\s(\d{4}-\d{2}-\d{2})\s(\d{2}:\d{2})?/;
      let startMatches = selection.match(startRegex);
      if (startMatches) {
        reminderDate = startMatches[1] ? startMatches[1] : "";
        reminderTime = startMatches[2] ? startMatches[2] : "";
      }
      reminderTime = reminderTime ? reminderTime : window.moment().format("HH:mm");

      // !提取deadline📅
      let dueRegex = /📅\s(\d{4}-\d{2}-\d{2})/;
      let dueMatches = selection.match(dueRegex);
      due = dueMatches ? dueMatches[1] : "";

      // !提取完成时间✅❌
      let doneDateRegex = /[✅❌]\s(\d{4}-\d{2}-\d{2})/;
      let doneDateMatches = selection.match(doneDateRegex);
      doneDate = doneDateMatches ? doneDateMatches[1] : "";

    } catch (e) {
      new Notice(`🔴无法获取选中的文本,请选重试!\nBug: \n${e}`);
      return;
    }

    // ! Bug:下拉选项无法设置默认值
    // !Fix: This helper returns a new list with the defValue item always being the first item.
    // !ref: https://github.com/danielo515/obsidian-modal-form/issues/227
    const moveDefaultToTop = (defValue, list) => {
      const orderedList = [...list];
      const index = orderedList.findIndex(item => item.value === defValue);
      if (index > 0) {
        const [item] = orderedList.splice(index, 1);
        orderedList.unshift(item);
      }
      return orderedList;
    };

    const recursOptions = [
      {
        "value": "",
        "label": "none"
      },
      {
        "value": "🔁 every day",
        "label": "每天"
      },
      {
        "value": "🔁 every week on Monday",
        "label": "星期一"
      },
      {
        "value": "🔁 every week on Tuesday",
        "label": "星期二"
      },
      {
        "value": "🔁 every week on Wednesday",
        "label": "星期三"
      },
      {
        "value": "🔁 every week on Thursday",
        "label": "星期四"
      },
      {
        "value": "🔁 every week on Friday",
        "label": "星期五"
      },
      {
        "value": "🔁 every week on Saturday",
        "label": "星期六"
      },
      {
        "value": "🔁 every week on Sunday",
        "label": "星期天"
      },
    ];

    const priorityOptions = [
      {
        "value": "",
        "label": "none"
      },
      {
        "value": "⏫",
        "label": "🔴重要且紧急⏫"
      },
      {
        "value": "🔼",
        "label": "🟠不重要但紧急🔼"
      },
      {
        "value": "🔽",
        "label": "🟡重要但不紧急🔽"
      },
      {
        "value": "⏬",
        "label": "🟢不重要且不紧急⏬"
      },
      {
        "value": "🔺",
        "label": "❗非常紧急且重要🔺"
      },
    ];

    let statusOptions = [
      {
        "value": " ",
        "label": "🔳ToDo"
      },
      {
        "value": "!",
        "label": "⚠Important"
      },
      {
        "value": "?",
        "label": "❓Question"
      },
      {
        "value": "/",
        "label": "⏳Doing"
      },
      {
        "value": "x",
        "label": "✅Done"
      },
      {
        "value": "-",
        "label": "❌Cancel"
      },
    ];
    const index = statusOptions.findIndex(item => item.value === status);
    if (index < 0) {
      statusOptions.push({
        "value": status,
        "label": `Unknown(${status})`
      });
    }

    // Modal Form Task表单
    const editorForm1 = {
      "title": "Creat or Edit Task",
      "name": "creat-or-edit-task",
      "fields": [
        {
          "name": "taskContent",
          "label": "Task Content",
          "description": "",
          "isRequired": true,
          "input": {
            "type": "textarea"
          }
        },
        // 设定s开始日期加时间
        {
          "name": "reminderDate",
          "label": "⏰",
          "description": "",
          "input": {
            "type": "date"
          }
        },
        {
          "name": "reminderTime",
          "label": "⏱",
          "description": "",
          "input": {
            "type": "time"
          }
        },
        // 设定deadline
        {
          "name": "due",
          "label": "📅",
          "description": "",
          "input": {
            "type": "date"
          }
        },
        // 重复周期,注意如果设定每2周,请手动添加罗马数字(2、3...),应该用不到吧......
        // eg:every 2 week on Thursday
        {
          "name": "recurs",
          "label": "重复(Recurs)",
          "description": "",
          "input": {
            "type": "select",
            "source": "fixed",
            "options": moveDefaultToTop(recurs, recursOptions)
          }
        },
        // ➕创建日期:
        {
          "name": "createdDate",
          "label": "🛫",
          "description": "",
          "input": {
            "type": "date"
          }
        },
        {
          "name": "createdTime",
          "label": "⏱",
          "description": "",
          "input": {
            "type": "time"
          }
        },
        {
          "name": "priority",
          "label": "优先级(Priority)",
          "description": "",
          "input": {
            "type": "select",
            "source": "fixed",
            "options": moveDefaultToTop(priority, priorityOptions)
          }
        },
        {
          "name": "status",
          "label": "状态(Status)",
          "description": "",
          "input": {
            "type": "select",
            "source": "fixed",
            "options": moveDefaultToTop(status, statusOptions)
          }
        },
        {
          "name": "tags",
          "description": "",
          "input": {
            "type": "tag"
          }
        },
      ],
    };

    let result = await modalForm.openForm(
      editorForm1,
      {
        values: {
          "taskContent": taskContent,
          "reminderDate": reminderDate,
          "reminderTime": reminderTime,
          "due": due,
          "recurs": "",
          "createdDate": createdDate,
          "createdTime": createdTime,
          "status": status,
          "tags": tags ? tags : settings["Tag"] || "",
        }
      }
    );
    if (!result) {
      return;
    }

    // 取消任务会自动添加终止时间❌,完成任务则是由task插件来添加✅,故不需要干预
    // 获取输入标签
    const getTags = result.getValue('tags').value;
    console.log("getTags", getTags);
    let tagsStr = "";
    if (getTags.length >= 1) {
      tagsStr = getTags.map(t => "#" + t.trim().replace("#", "")).join(" ");
    } else {
      tagsStr = "";
    }
    // task的基本内容
    const task_content = result.getValue('taskContent').value.replace(/\n/gm, "<br>");
    const task_status = result.getValue('status').value;
    let task_doneDate = "";
    if (task_status === "x") {
      task_doneDate = "✅ " + (doneDate ? doneDate : String(window.moment().format("YYYY-MM-DD")));
    } else if (task_status === "-") {
      task_doneDate = "❌ " + (doneDate ? doneDate : String(window.moment().format("YYYY-MM-DD")));
    }

    // task的安排获取
    // !任务创建日期
    const task_creatDate = result.getValue('createdDate').value ? "🛫 " + result.getValue('createdDate').value : "";
    // 如果没有日期,则不显示时间
    // const task_creatTime = task_creatDate ? result.getValue('createdTime').value : "";
    let task_creatTime = result.getValue('createdTime').value ? result.getValue('createdTime').value : "";
    console.log(task_creatTime, hours, minutes);
    // 修正推断出createdTime2的逻辑
    const task_creatTime2 = window.moment(task_creatTime, 'HH:mm').add(hours, 'hours').add(minutes, 'minutes').format('HH:mm');
    console.log(`延迟后时间: ${task_creatTime2}`);
    if (task_creatTime && task_creatTime !== task_creatTime2) {
      task_creatTime = `${task_creatTime} - ${task_creatTime2}`;
    }

    // !任务提醒日期
    const task_reminderDate = result.getValue('reminderDate').value ? "⏰ " + result.getValue('reminderDate').value : "";
    // 如果没有日期,则不显示时间
    const task_reminderTime = task_reminderDate ? result.getValue('reminderTime').value : "";

    // !deadline Time
    // 注意事项,如果存在task_reminderDate但不存在due,则无法提醒,故当due不存在时,采用与reminderDate相同的日期。
    const task_due = result.getValue('due').value ? "📅 " + result.getValue('due').value : task_reminderDate.replace("⏰", "📅");

    // !任务优先级
    const task_priority = result.getValue('priority').value;
    // !任务周期
    const task_recurs = result.getValue('recurs').value;

    console.log(tagsStr, task_content);

    const output = (type ? `${startStr} \[${task_status}\] ` : `${startStr} `) +
      `${task_creatTime} ${tagsStr} ${task_content} ${task_reminderDate} ${task_reminderTime} ${task_priority} ${task_recurs} ${task_creatDate} ${task_due}  ${task_doneDate}`.replace(/\s+/g, " ").trim();

    console.log(output);

    // 替换当前行文本
    const line = editor.getLine(editor.getCursor().line);
    editor.replaceRange(output, { line: editor.getCursor().line, ch: 0 }, { line: editor.getCursor().line, ch: line.length });
    // 光标移动到末尾
    editor.setCursor({ line: editor.getCursor().line, ch: output.length });
  },
  settings: {
    name: "创建或编辑Task任务",
    author: "熊猫别熬夜",
    options: {
      "Tag": {
        type: "text",
        defaultValue: "",
        description: "设置默认标签,eg: #Project/学习"
      },
      "AutoCreatedDate": {
        type: "toggle",
        defaultValue: true,
        description: "是否自动插入创建日期(➕)"
      },
      "AutoTime": {
        type: "toggle",
        defaultValue: true,
        description: "是否自动插入时间前缀(HH:mm)"
      },
    }
  }
};

拓展: 【CSS】Modal Form 界面调整

这段 CSS 会让编辑界面更加紧凑一点

.modal-content.modal-form {
  .setting-item:has(.dropdown, .checkbox-container) ,
  .setting-item:has(input[type="date"], input[type="time"]) {
    display: inline-flex;
    grid-template-columns: auto;
    grid-column: auto;
    flex-wrap: wrap;
    margin-left: 10px;
    margin-right: 10px;
    border: 0;
    width: auto;
    justify-items: start;
    justify-content: space-between;
  }
}

基于 Canvas 构建的四象限任务管理系统

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--基于 Canvas 构建的四象限任务管理系统

可以利用 Task Queries 查询任务,并利用 Canvas 排布为四象限结构,我这里利用了 QuickAdd 脚本 - 利用 Canvas 平铺笔记 的脚本对文档进行转换:

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--基于 Canvas 构建的四象限任务管理系统

利用 Task 自带任务编辑器可以调整任务状态:

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--基于 Canvas 构建的四象限任务管理系统

PS: 建议把该 Canvas 界面🔒锁定住,用 Task 创建分类

四象限任务管理的 Task 查询文档

Task 的查询语法详细请阅读: https://publish.obsidian.md/tasks ,作者写的很详细,每个版本更新内容都说明了,功能非常丰富。


# 重要且紧急

```tasks
priority is above medium
group by status.name
limit 10
sort by priority
starts in this month
```

# 不重要但紧急

```tasks
priority is medium
hide priority

group by status.name
limit 10
sort by due
starts in this month
```

# 重要但不紧急

```tasks
priority is low
hide priority

group by status.name
limit 10
sort by due
starts in this month
```

# 不重要且不紧急

```tasks
priority is lowest
hide priority

group by status.name
limit 10
sort by due
starts in this month
```

# 未规划任务

```tasks
priority is none
hide priority
not done
group by function task.file.filename
limit 20
sort by due
starts in this month
path regex does not match /(010|200)/
```

在“任务查询结果”中,默认情况下,每个任务都显示其文件名和上一个标题的名称,例如 (ACME > Steps to world domination) 。这称为反向链接 (BackLink)。

虽然可以使用 short mode 模式,它会用图标替换反向链接文本,但这会隐藏任务的所有其他属性,例如截止日期和重复周期。

也可以使用 hide backlink 直接不显示反向链接,但这样将失去导航到源文件的能力。

简单修改颜色及透明度

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--简单修改颜色及透明度

/* By David Phillips (autonia) https://github.com/autonia
   From https://github.com/obsidian-tasks-group/obsidian-tasks/discussions/622#discussioncomment-2649299
*/
.tasks-backlink {
    font-size: 0.7em;
    opacity: 0.6;
    filter: grayscale(60%);
}

使用 CSS 将反向链接替换为图标

基于 QuickAdd+Modal Form 的任务 (Task) 编辑器--使用 CSS 将反向链接替换为图标

/* By Anna Kornfeld Simpson (@AnnaKornfeldSimpson) https://github.com/AnnaKornfeldSimpson
   From https://github.com/obsidian-tasks-group/obsidian-tasks/discussions/834#discussioncomment-3028600

   Then converted to embed the icon inside this .css file, to remove the need
   for an internet connection, as follows:
   1. Link icon downloaded from https://twemoji.twitter.com
      https://github.com/twitter/twemoji/blob/master/assets/svg/1f517.svg
      licensed under the CC-BY 4.0
   2. SVG encoded for embedding here with https://yoksel.github.io/url-encoder/

Tasks 3.0.0 compatibility note.

    Prior to Tasks 3.0.0, the first CSS line below was the following, with a '>'
    separator.

li.plugin-tasks-list-item > span.tasks-backlink > a {
*/
li.plugin-tasks-list-item span.tasks-backlink > a {
    height: .9em;
}

讨论

若阁下有独到的见解或新颖的想法,诚邀您在文章下方留言,与大家共同探讨。



反馈交流

其他渠道

版权声明
