引言

自定义优化文件管理器中的文件夹样式图标

实践

Obsidian 样式：美化自定义文件夹图标--实践

方案

  • 使用 svg

[!NOTE] 下面的步骤针对所有的文件夹和文件图标修改。有其他需求（修改指定文件夹的图标）则需要自行分析得到文件夹元素的选择器。

快速设置

Warning

为了避免对默认（主题） 样式造成侵入性，建议使用 css snippets 进行样式的设置。比如在 .obsidian/snippets 文件夹下创建一个 .css 文件，假设名为 custom-folder-icon.css。

步骤 1，创建 custom-folder-icon.css 并在 文件中粘贴如下的代码

Obsidian 样式：美化自定义文件夹图标--快速设置

/* 设置文件夹图标 */
.nav-folder-children .nav-folder-title-content::before {
	content: '';
	background-size: 20px 20px;
	transform: translate(0, 4px);
	background-repeat: no-repeat;
	display: inline-block;
	height: 20px;
	width: 20px;
	margin-right: 4px;
}
/* 设置 文件图标 */
.nav-folder-children .nav-file-title-content:first-child::before {
	content: '';
	background-size: 20px 20px;
	transform: translate(0, 4px);
	background-repeat: no-repeat;
	display: inline-block;
	height: 20px;
	width: 20px;
	margin-right: 4px;
}
Info

经过测试，控制宽度 width 和高度 height 在 64px 效果比较好
Obsidian 样式：美化自定义文件夹图标--快速设置

步骤 2，修改图标使用自定义的图标代码

1,准备你喜欢的图标的 svg 格式代码

形如 <svg>...</svg>

可以从这个 网站 找到一个喜欢的图标（或者你有其他途径也行）。

然后点击这个按钮 Obsidian 样式：美化自定义文件夹图标--快速设置

Obsidian 样式：美化自定义文件夹图标--快速设置

复制 SVG 代码

Obsidian 样式：美化自定义文件夹图标--快速设置

2,使用这个 网站 将其转为 base64 字符串

Obsidian 样式：美化自定义文件夹图标--快速设置


3,将这个字符串作为 background-image: url(<base64字符串>) 的内容

步骤 3，在 Obsidian 中启用 custom-folder-icon.css 文件对应的样式选项

Obsidian 样式：美化自定义文件夹图标--快速设置

Obsidian 样式：美化自定义文件夹图标--快速设置

步骤 4，在 Obsidian 主页观察文件夹图标变化

预览效果：

Obsidian 样式：美化自定义文件夹图标--快速设置

也可以按照设置文件夹的方式设置文件（参照 css 代码中的内容）

整体的效果如下

Obsidian 样式：美化自定义文件夹图标--快速设置

对比没设置图标的效果

Obsidian 样式：美化自定义文件夹图标--快速设置

Note

如果熟悉 css ，则可以进一步美化

指定文件后缀文件图标

上述的设置是统一对所有文件夹和文件进行图标设置。如果是文件夹还好说，对于文件，有不同的类型，如果都设置为 markdown 图标则区分不开。

可以单独对指定类型（文件后缀）的文件设置图标。比如为 .md 后缀文件设置 markkdown 图标，给 .png,.jpg 等图标文件设置图片图标。

如果也想快速设置，则需要简单几步

步骤 1，知道要指定自定义图标文件的后缀信息

以 windows 为例，所有文件后缀信息可以从 网页 中查找

步骤 2，准备图标 svg 转为 base64 的代码（参考上面 快速设置）

步骤 3，添加 css snippet 中的代码

只需要修改两处

1）文件后缀

将 .md 修改为你要自定义图标的文件的文件后缀。如修改为 .png 表示指定为 .png 文件设置图标

div[data-path$='.md']

2）图标

同样替换 <图标svg转为base64的代码> 为自定义的图标代码

background-image: url("<图标svg转为base64的代码>")

下面给出了设置 图片, gif,markdown 文件类型图标的样式代码，可以参考修改

/* 设置 markdown文件图标 */
.nav-folder-children
	.tree-item.nav-file
	div[data-path$='.md']
	.nav-file-title-content::before {
	content: '';
	background-size: 20px 20px;
	transform: translate(0, 4px);
	background-repeat: no-repeat;
	display: inline-block;
	height: 20px;
	width: 20px;
	margin-right: 4px;
}
/* 设置 图片文件图标 */
.nav-folder-children
	.tree-item.nav-file
	div[data-path$='.png']
	.nav-file-title-content::before,
.nav-folder-children
	.tree-item.nav-file
	div[data-path$='.jpg']
	.nav-file-title-content::before,
.nav-folder-children
	.tree-item.nav-file
	div[data-path$='.jpeg']
	.nav-file-title-content::before {
	content: '';
	background-size: 20px 20px;
	transform: translate(0, 4px);
	background-repeat: no-repeat;
	display: inline-block;
	height: 20px;
	width: 20px;
	margin-right: 4px;
}
/* 设置 gif 文件后缀 */
.nav-folder-children
	.tree-item.nav-file
	div[data-path$='.gif']
	.nav-file-title-content::before {
	content: '';
	background-size: 20px 20px;
	transform: translate(0, 4px);
	background-repeat: no-repeat;
	display: inline-block;
	height: 20px;
	width: 20px;
	margin-right: 4px;
}

效果如下

Obsidian 样式：美化自定义文件夹图标--指定文件后缀文件图标

资源

（完）
