Obsidian 样式：文件浏览器样式

cuman 于 2023-07-03 10:46 发布

分类专栏：

obsidian外观

文章标签：

#Obsidian #css #文件浏览器 #插件 #样式

Obsidian 样式：文件浏览器样式

概述

Obsidian 自带的文件浏览器，样式单一，有很大的改造余地，通过 css 可以让文件夹变的更醒目更个性化。

通过使用自定义样式来完成，使用方法参考 Obsidian的CSS代码片段

文件夹添加图标

根据自己的文件夹名称，把名称写到 css 中就可以自定义文件夹图标，其中文件夹图标使用的是 svg 格式，iconfont-阿里巴巴矢量图标库这里有很多图标可供选择。css 中 svg 图标需要转成 base64 格式才能正确解析，通过这个网页实现转换 SVG to CSS converter | SVG Backgrounds

效果

假设这里的文件夹名称为 000 Inbox，100 Projects 等

Obsidian 样式：文件浏览器样式--效果

代码

/* Obsidian snippet to add icons to certain folders in the explorer view */
.nav-file-title-content, .nav-folder-title-content
{
display: flex;
}
.nav-folder .nav-folder-title[data-path="000 Inbox"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="100 Projects"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="200 Areas"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="300 Resources"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="400 Archives"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="999 Templates"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

.nav-folder .nav-folder-title[data-path="Daily Notes"] .nav-folder-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

文件添加图标

为了突出某个文件，可以对这个文件进行样式设计，比如加一个醒目的图标。

效果

假设有个文件名称为 Workbench.md

Obsidian 样式：文件浏览器样式--效果

代码

.nav-file .nav-file-title[data-path="Workbench.md"] .nav-file-title-content::before{
  margin: 0 4px 0 0;
  height: 17px;
  width: 17px;
  display: inline-block;
  content: "";
  background-size: 17px 17px;
  background-repeat: no-repeat;
  background-position-y: 1px;
}

突出文件类型

Obsidian 样式：文件浏览器样式--突出文件类型


.nav-file .nav-file-title[data-path*=".pdf"] .nav-file-tag{
    background-color: rgb(240, 167, 182);
    color:white;
}

.nav-file .nav-file-title[data-path*=".png"] .nav-file-tag{
    background-color: rgb(100, 100, 168);
    color:white;
}

.nav-file .nav-file-title[data-path*=".jpg"] .nav-file-tag{
    background-color: rgb(100, 168, 124);
    color:white;
}
.nav-file .nav-file-title[data-path*=".svg"] .nav-file-tag{
    background-color: rgb(237, 182, 131);
    color:white;
}

多彩文件夹样式

Obsidian样式-多彩文件夹样式

讨论

若阁下有独到的见解或新颖的想法，诚邀您在文章下方留言，与大家共同探讨。
